The Hayward YSH Series 1-1/2" Y-Strainer is built from CPVC (CPVC Cell Class 23447 per ASTM D1784) and features True Union Socket & Threaded end connections with CPVC end connection material with a reliable EPDM o-ring seal.

• Pipe Size: 1-1/2"
• Body Material: CPVC
• Basket/Screen Material: CPVC
• End Connection: True Union Socket & Threaded
• Sealing Material: EPDM
• Cv Coefficient: 28.0
• Pressure Rating: 150 PSI @ 70 °F
• Available Screen Perforations: 1/16", 1/32", 1/8", 3/16"

Designed with new safety features including exterior buttress threads and a pressure-relieving chamfered barrel nut. Optional hex cap for fast screen access, pre-drilled cap taps for blow-out or gauge ports, and clear PVC screens for quick visual inspection. Installs horizontally or vertically. Optional mesh screens from 20 to 325 mesh available in stainless steel, PVDF, Hastelloy, titanium, and Monel.
