The Hayward YSH Series 1/2" Y-Strainer is built from PVC (PVC Cell Class 12454 per ASTM D1784) and features Integral Threaded end connections with a reliable FPM (Viton ®) o-ring seal.

• Pipe Size: 1/2"
• Body Material: PVC
• Basket/Screen Material: PVC
• End Connection: Integral Threaded
• Sealing Material: FPM (Viton ®)
• Cv Coefficient: 4.0
• Pressure Rating: 150 PSI @ 70 °F
• Available Screen Perforations: 1/16", 1/32", 1/8", 3/16"

Designed with new safety features including exterior buttress threads and a pressure-relieving chamfered barrel nut. Optional hex cap for fast screen access, pre-drilled cap taps for blow-out or gauge ports, and clear PVC screens for quick visual inspection. Installs horizontally or vertically. Optional mesh screens from 20 to 325 mesh available in stainless steel, PVDF, Hastelloy, titanium, and Monel.
